Основні параметри
Модель | DN | PN | Монт. отвори | D | A | L | H | CxC | ISO5211 | Вага (кг) |
|---|---|---|---|---|---|---|---|---|---|---|
| 2118 04 | 1/2″ | 16 | 4xM12 | 95 | 80 | 36 | 9.5 | 9×9 | F03 | 1.7 |
| 2118 05 | 3/4″ | 16 | 4xM12 | 105 | 85 | 38 | 13 | 9×9 | F03 | 1.9 |
| 2118 06 | 1″ | 16 | 4xM12 | 115 | 95 | 50 | 10 | 11×11 | F04/F05 | 2.5 |
| 2118 07 | 1 1/4″ | 16 | 4xM16 | 140 | 100 | 53 | 12.5 | 11×11 | F04/F05 | 3.5 |
| 2118 08 | 1 1/2″ | 16 | 4xM16 | 150 | 105 | 65 | 14.5 | 14×14 | F05/F07 | 4.35 |
| 2118 09 | 2″ | 16 | 4xM16 | 165 | 115 | 78 | 14 | 14×14 | F05/F07 | 5.45 |
| 2118 10 | 2 1/2″ | 16 | 4xM16 | 185 | 130 | 98 | 17 | 17×17 | F07/F10 | 7.8 |
| 2118 11 | 3″ | 16 | 4xM16 | 200 | 145 | 118 | 16 | 17×17 | F07/F10 | 10.3 |
| 2118 12 | 4″ | 16 | 4xM16 | 220 | 175 | 140 | 19 | 17×17 | F07/F10 | 18.0 |
